| Optical System Specifications |
|
Optical System |
Finite |
| System Optical Magnification |
6.7-45X |
| Expandable System Optical Magnification(Optional Parts Required) |
2-270X |
| Standard Eyepiece |
10X High Eyepoint Eyepiece |
| Standard Objective |
1X Built-in Objective |
| System Field of View |
Φ4.9-32.8mm |
| Expandable System Field of View |
Φ1-109.5mm |
| System Working Distance |
100mm |
| Expandable System Working Distance |
26-287mm |
| Binocular Zoom Body |
|
Body Optical System |
Finite |
| Body Magnification |
6.7-45X |
| Zoom Range |
0.67-4.5X |
| Zoom Ratio |
1:6.7 |
| Zoom Operating Mode |
With Two Horizontal Knobs |
| Observe Method |
Binocular |
| Body Mounting Size for Stand |
Φ76mm |
| The Nosepiece Adapter Size for Ring Light |
Φ54mm |
| Eyetube Adjustment Mode |
Compensating |
| Eyetube Angle |
45° |
| Erect/Inverted Image |
Erect image |
| Eyetube Rotatable |
360° Rotatable |
| Interpupillary Adjustment |
54-75mm |
| Eyetube Inner Dia. |
Φ30mm |
| Eyetube Diopter Adjustable |
±5° |
| Eyepiece Type |
Standard Eyepiece |
| Eyepiece Optical Magnification |
10X |
| Plan Eyepiece |
Plan Eyepiece |
| Eyepiece Size for Eyetube |
Φ30mm |
| Eyepiece Field of View |
Φ22mm |
| Eyepoint Type |
High Eyepoint Eyepiece |
| Eyepiece Size for Reticle |
Φ24mm |
| Eye Guard Installation |
Indepent Eye Guard |
| Eye Guard Material |
Rubber |
| Eye Guard Mount Size |
Φ36mm |
| Objective Working Distance |
100mm |
| Surface Treatment |
Spray Paint |
| Material |
Metal |
| Color |
White |
| Net Weight |
1.46kg (3.22lbs) |
| 76mm Track Stand |
Stand Type |
Track Stand |
| Holder Adapter Type |
Φ76mm Scope Holder |
| Track Length |
325mm |
| Base Type |
Table Base |
| Base Shape |
Rectangle |
| Stand Throat Depth |
121mm |
| Base Dimensions |
320x305x16mm |
| Focus Mode |
Manual |
| Focus Distance |
200mm |
| Coarse Focus Distance per Rotation |
23mm |
| Focusing Knob Tightness Adjustable |
Tightness Adjustable |
| Surface Treatment |
Spray Paint |
| Material |
Metal |
| Color |
White |
| Net Weight |
3.10kg (6.83lbs) |
| Dimensions |
320x305x341mm (12.598x12.008x13.425″) |
