Introduction
Introduction：
Desktop Digital Stereotaxic Instument exhibits all the features of the Standard Stereotaxic Instrument, and it has a sealed electronic sensor and compact LCD display, which real-time shows the coordination of all three axes with 10 micron resolution. And the zeroing function simplifies the targeting process. To be adequate for the electrophysiology experiment, this instrument utilizes battery instead of AC power, which dramatically reduces electronic noise, and keeps the workbench tidy. The standard Stereotaxic instrument can be upgraded to Digital Stereotaxic with the Desktop Digi, SGL, Module.。
Specification：
Adaptors available for use with rats, mice, birds, cats, , geckos, guinea pigs and other species
Working distance for each 3-diamention is 80 mm with precise alignment to 10µm resolution.
Vertical direction: 180° rotation and lock at any angles
Horizontal direction: 360° rotation and lock at any angles
Laser engraved scales, darken rod and open U-shape frame make numerals easy to read
Dual-lead screws ensure stable and accurate manipulation
Maintain accuracy and flexibility at different temperatures
The surface of base and frame are coated with manufacturer applied treatment that resists stains and wearing.
Zeroing function can be done at any X, Y, Z axis coordinates on the display, to avoid secondary readings and calculations , simplifies the process of experimental operation
Battery can be used for long time, without electronic noise，suit for electrophysiology studies.
Extended base plate 400mmX255mm is available
Vertical lock and fixing knob are separated to ensure accurate position at any angle
The precisely-designed rotary knob and the U frame supply sufficient space for the anterior-posterior operation (28mm)
Curve design of nose clamp secures the head of the animals more steady.
Use plate pressing rather than clamping in locking the Ear bar, to ensure stability.
Syringe pump, microcamera and drill can be attached to the Stereotaxic Instruments directly.
Order Information:
|
Cat No.
|
Product Description
|
|
68016
|
Stereotaxic, Desktop Digi,SGL M,w/mouse 68010
|
|
68017
|
Stereotaxic, Desktop,Digi,Dual M,w/mouse 68010
|
|
68018
|
Stereotaxic, Desktop,Digi,SGL M,w/mouse 68030
|
|
68019
|
Stereotaxic, Desktop,Digi,Dual M,w/mouse 68030
|
|
68025
|
Stereotaxic,Desktop,Digi,SGL M,18 Deg. Ear Bars
|
|
68026
|
Stereotaxic,Desktop,Digi,Dual M,18 Deg. Ear Bars
|
|
68027
|
Stereotaxic,Desktop,Digi,SGL M,45 Deg. Ear Bars
|
|
68028
|
Stereotaxic,Desktop,Digi,Dual M,45 Deg. Ear Bars
|
|
Configurations
Cat No.
|
68016
|
68017
|
68018
|
68019
|
68025
|
68026
|
68027
|
68028
|
|
Base including U-Frame and Base Board 68503
|
1
|
1
|
1
|
1
|
1
|
1
|
1
|
1
|
|
Mainp,3 AXES,LH(Including Two Screws) 68401
|
1
|
1
|
1
|
1
|
1
|
1
|
1
|
1
|
|
Mainp,3 AXES,RH(Including Two Screws) 68402
|
|
1
|
|
1
|
|
1
|
|
1
|
|
Update for Mainp,3 AXES,to Desktop Digi 68023
|
1
|
2
|
1
|
2
|
1
|
2
|
1
|
2
|
|
Rat Adaptor-Nose Clamp 68021
|
|
|
|
|
1
|
1
|
1
|
1
|
|
Mouse Adaptor 68010
|
1
|
1
|
|
|
|
|
|
|
|
Mouse/Neonatal Rat Adaptor (Including 18 Deg and 45 Deg Ear Bars) 68030
|
|
|
1
|
1
|
|
|
|
|
|
Ear Bars,Pairs,Rat,18 Deg 68301
|
|
|
|
|
1 pair
|
1 pair
|
|
|
|
Ear Bars,Pairs,Rat,45 Deg 68302
|
|
|
|
|
|
|
1 pair
|
1 pair
|
|
Probe Holder-Corner 68201
|
1
|
2
|
1
|
2
|
1
|
2
|
1
|
2
|
